10AWG Silicone Rubber Wire 1050/0.08 Tinned Copper UL758

Place of Origin Guangdong, China
브랜드 이름 MYSUN
인증 UL Certification
Model Number E239689
Minimum Order Quantity 3050
가격 $0.01-0.02

무료샘플과 쿠폰을 위해 나와 연락하세요.

왓츠앱:0086 18588475571

위챗: 0086 18588475571

스카이프: sales10@aixton.com

만약 당신이 어떠한 관심도 가지면, 우리가 24 시간 온라인 도움말을 제공합니다.

x
제품 상세 정보
Conductor Material Tinned Copper wire Insulation Material Silicone Rubber
Rated Voltage 600V Conductor Type Tinned Copper
AWG Size 10 Conductor Construction 1050/0.08
Conductor Diameter 3.40±0.30 mm Insulation Thickness 1.15 mm
Overall Diameter 5.50±0.2 mm Temperature Range High Temperature
Wire Flexibility Super Soft Color Options Optional
Conductor Core Copper Jacket Material Silicone Rubber
Wire Standard UL 758
강조하다

10AWG silicone rubber wire

,

tinned copper silicone wire

,

UL758 silicone insulated wire

메시지를 남겨주세요
제품 설명
Super Soft Silicone Wire 1050/0.08 10AWG High Temperature Battery Cable
Product Specifications
Attribute Value
Type Insulated
Application Home appliance, lighting, heater, motor & generator
Conductor Material Tinned Copper wire
Conductor Type Tinned copper
Insulation Material Silicone Rubber
Rated voltage 600V
Standard UL 758
Color Optional
Product Description
Supplies Fortune 500, Top Silicone Rubber Wire Supplier In China.
10AWG Silicone Rubber Wire 1050/0.08 Tinned Copper UL758 0 10AWG Silicone Rubber Wire 1050/0.08 Tinned Copper UL758 1
Technical Specifications
Conductor Insulation
Size (AWG) Construction (No./mm) Diameter (mm) Nominal Thickness (mm) Diameter (mm)
26 25/0.08 0.48 0.78 2.10±0.1
24 41/0.08 0.60 0.78 2.20±0.1
22 65/0.08 0.78 0.78 2.50±0.1
20 104/0.08 0.95 0.78 2.55±0.1
18 164/0.08 1.17 0.78 2.80±0.1
16 261/0.08 1.47 0.78 3.10±0.1
14 415/0.08 2.10 0.78 3.70±0.1
12 660/0.08 2.70 0.78 4.30±0.1
10 1050/0.08 3.40±0.30 1.15 5.50±0.2
Contact Us to Get the Most Cost-effective Quote
10AWG Silicone Rubber Wire 1050/0.08 Tinned Copper UL758 2 10AWG Silicone Rubber Wire 1050/0.08 Tinned Copper UL758 3 10AWG Silicone Rubber Wire 1050/0.08 Tinned Copper UL758 4 10AWG Silicone Rubber Wire 1050/0.08 Tinned Copper UL758 5
Frequently Asked Questions
  • Who Are We? We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience.
  • What Can We Provide? High-temperature wires and cables, silicone tubing including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, wiring harnesses.
  • Why Choose Us? Free samples, competitive pricing, high quality standards, and customized service.
  • What Certifications Do We Have? UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC certification.
  • What Services Can We Provide? Accepted delivery terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted payment currency: USD, EUR, CNY. Accepted payment type: T/T, L/C, PayPal, Western Union, Cash.
